IPS-C13 Stepper Motor Controller

Product Description

This is a special operation control module for single shaft stepping motor.A variety of fixed operation modes are built in the module, and users can quickly select the appropriate motion track. The distance / speed / delay / number of cycles can be saved and set after power down. It can run independently as a module, or it can be used together with other systems. It can be used in general industrial control occasions, not in special industries such as medical treatment and fire protection or life-threatening fields.

Technical Parameters

Model	IPS-C13
Adaptive Motor	Stepping Motor
Number Of Control Axes	Single Axis
Motor Signal	Common Cathode
Power Supply Range	DC 10-30V General
Driving Capacity	4A
Instruction Features	Streamline and optimize multiple common instructions
Acceleration and deceleration control	Yes
Input reverse connection protection	Yes
Remote communication control	TTL Serial Port
Main Functions Of The System	Automatic, Manual, Setting And Serial Port Control
Speed Range	0.1 ~ 999 laps / min
Number Of Forward Rotation Pulses	1-9999999 pulses
Number Of Reverse Pulses	1-9999999 pulses
Number Of Cycles	1-9999
Forward Rotation Delay Time	0.0-999.9 seconds
Reverse Delay Time	0.0-999.9 seconds
Subdivision Detection Range	1-128 subdivision
Product Service Environment	-5°C~ +60°C
